Overview

Data Connection supports exporting datasets and streams from Foundry to external systems. This can be useful for a variety of purposes:

• Data cleaned and transformed in Foundry using data pipelines can be synced to systems such as data warehouses or data lakes. This pattern is described in greater detail in "How Palantir Foundry Fuels Your Data Platform" ↗.
• Inference results from machine learning models created using batch deployments can be exported to other systems to enable operationalizing ML projects across the organization.
• Operational data captured from end users in the Ontology can be written to other systems for analysis outside of Foundry.

Enable exports for source

To export data, you must enable exports in the Connection settings section of the source to which you are exporting. Source types that support exports will show an Export configuration tab to the left of the screen. A Foundry user with the Information Security Officer role should navigate to this tab and toggle on the option to Enable exports to this source.

The Information Security Officer is a default role in Foundry; users can be granted the Information Security Officer role in Control Panel under Enrollment permissions.

After enabling exports, you must provide the set of Markings that may be exported to this source. If Markings and Organizations are not added in the export configuration, data with those Markings or Organizations will fail to export to this source. To add an exportable Marking, a user must be both an Information Security Officer and have unmarking permission on the Markings or Organizations they wish to allow to be exported to this source.

As an example, you may have a dataset with a Sensitive marking in the Palantir organization. To export this dataset, you must add both the Sensitive marking and the Palantir organization to the set of Exportable markings for this source.

Create a new export

To create an export, first navigate to the Overview page of the source to which you want to export.

If this is the first export you are setting up for the given source, you will see an empty table and a button to create an export.

Select Create export, then select the dataset or stream to export and any source-specific export configuration options. These options will vary by source connector and are explained on the corresponding source type pages in our documentation. If multiple branches exist on the exported dataset, only data on the master branch will be exported.

The example below shows the export configuration interface for the S3 connector:

After saving the export, you will land on the export management page where you can do the following:

• Manually run the export.
• Set a schedule for the export.
• View export history.
• Modify configuration options.

Export types

The behavior of exports will depend on the type of data the destination system can accept.

File exports

An example of a system supporting file exports is S3.

File exports write files from the selected Foundry dataset to the configured destination. By default, only files that were modified since the last successfully exported transaction on the upstream dataset will be written. This means that if a file was not updated in a given transaction, it will not be re-exported on the next scheduled or manual run of any downstream exports.

If the entire dataset must be re-exported, set up a new export on the same source or ensure your upstream transformation overwrites all files that must be exported.

By default, if a file already exists in the destination, export jobs will overwrite that file with the exported data. This behavior may vary by source type. To avoid accidentally overwriting data stored in the destination system, we recommend creating a dedicated sub-folder in which to land exported data from Foundry.

Streaming exports

An example destination that supports streaming exports is Kafka.

Exports to streaming destinations will stream records to the destination as long as the export job is running in Foundry. If the job is stopped and restarted, it will resume streaming records from where it left off.

Streaming export replay behavior

When configuring an export to a streaming destination, you must specify the desired behavior for when the stream is replayed in Foundry. Normally, streams are replayed after making breaking changes to the processing logic. In this case, previously processed records must be re-processed using the new logic in one of the following ways:

• Export replayed records: Re-export all records when the stream is replayed. Note that any previously exported records will be exported again, and the external system must be configured to handle duplicates.

• Do not export replayed records: Pause exports until the replayed offset matches the most recent offset in the export job. Because offsets are not guaranteed to match across replayed streams, this option often results in some number of dropped records that will never be exported.

Table exports

Table exports allow exports to systems that contain tabular data with a known schema, where the external target schema matches the schema of a Foundry dataset you wish to export. Table exports will execute the system-specific INSERT statements or equivalent API calls to write rows into the target table according to the selected table export mode as described below.

Table export modes

The selected export mode specifies how data will be exported during a table export. The following export modes are available for all table exports and are also explained on the export setup page in Data Connection.

Export modes are not available for legacy export tasks.

SQL dialects in table exports

Table exports are currently supported for custom JDBC source types. Though Foundry provides dedicated connectors for specific systems such as Oracle, the table exports source capability will not appear as an option unless the connection is established via the custom JDBC connection.

Supported JDBC source types

When performing table exports to a custom JDBC source for which you've provided your own driver JAR file, you must confirm that Palantir's INSERT statement syntax for exporting data is compatible with the SQL dialect that your system will accept.

Below, you can find examples of the INSERT statements used by Palantir for exports to custom JDBC sources. These statements cannot currently be customized. If your system does not accept the statements used when running exports, you can fall back on code-based connectivity options to write to your system.

You must also ensure that the types used in your database are compatible with the supported types listed below.

List of supported types

Supported JDBC source types include:

• DECIMAL
• BIGINT
• BINARY
• BOOLEAN
• SMALLINT
• DATE
• DOUBLE
• FLOAT
• INTEGER
• VARCHAR
• TIMESTAMP

List of unsupported JDBC source types

Unsupported JDBC source types include:

• ARRAY
• MAP
• STRUCT
• Other types not listed as supported above (such as less-common types like GEOGRAPHY)

If your dataset contains columns of unsupported types (such as ARRAY, MAP, or STRUCT), the export will fail.

Examples of INSERT statements that will be triggered by table exports

The examples below provide more information about the syntax used by table exports. If your source system does not support INSERT statements in this format, the INSERT statements will fail at runtime.

Assume that a target_table exists within our source system, with the same schema as the corresponding dataset in Foundry. Both the names and datatypes of the columns must match between the external source and Foundry. Below is a mock example of a dataset in Foundry:

The INSERT statement for a single row follows the general format below:

INSERT INTO target_table (column1, column2, column3) VALUES ('value1', 'value2', 'value3');

Depending on source type, an insert statement will be applied against one or multiple rows of data. For example, Snowflake supports batch inserts and thus permits multiple rows to be written at once.

INSERT INTO target_table (column1, column2, column3) VALUES ('value1', 'value2', 'value3'), ('value4', 'value5', 'value6'), ('value7', 'value8', 'value9');

By contrast, a source like Apache Hive has limited support for batch inserts and will undergo an export via three subsequent insert statements.

INSERT INTO target_table (column1, column2, column3) VALUES ('value1', 'value2', 'value3');
INSERT INTO target_table (column1, column2, column3) VALUES ('value4', 'value5', 'value6');
INSERT INTO target_table (column1, column2, column3) VALUES ('value7', 'value8', 'value9');

Example TRUNCATE TABLE statement

Export options like Full dataset with truncation will first truncate the target table at the external source, then run an insert statement. The actual code to accomplish this would look like the example below:

TRUNCATE TABLE table_name;
INSERT INTO target_table (column1, column2, column3) VALUES ('value1', 'value2', 'value3');

Next steps

If a more specific dialect is needed, we recommend one of Foundry's code-based connectivity options such as external transforms.

Special considerations for table exports

• The dataset you export from Foundry must have a 1:1 match with the external source, including exact column names (case-sensitive) and data types. For example, exporting COLUMN_ABC of type LONG to a destination where COLUMN_ABC is of type STRING will fail at runtime.
• When setting up a table export, ensure that DATABASE, SCHEMA, and TABLE fields are filled out if required by your source. Missing any of these fields will cause the export to fail at runtime. Similarly, including unnecessary fields can also result in failure. For highest reliability, use explore source and autofill to select the destination in your source.
• When using an agent runtime with table exports, the agent must be running on a Linux host. Windows agents are not supported for running table exports.
• The underlying files for a dataset being exported to a tabular destination must be in Parquet format. CSV and other file types that support a schema will fail to export.
• The destination table must already exist in the source system; it will not be automatically created by Foundry.
• When using an export mode that does truncation, the credentials entered in the Foundry source configuration must have permissions to truncate the table in the external system.
• Array, Map, and Struct types are not supported for exports. If the dataset you are exporting contains a column with type Array, Map, or Struct, the export will fail.

Scheduling exports

Exports should be scheduled to run regularly, exporting recent data to the external destination. Streaming exports do not need to be scheduled since they should simply be started or stopped.

To schedule an export, navigate to the Overview page for the export. Then, select Add schedule to open the export in Data Lineage. From there, select Create new schedule to the right of your screen and configure as you would for any other job. Learn more about available scheduling options.

View any schedules that trigger a specific export on the Overview page for that export, as shown below:

Export history

Similar to syncs, exports run as jobs using the Foundry build system. The History view of an export shows the history of the jobs associated with it. Each job may be opened and viewed in the Builds application by selecting View build report to the upper right of the Job details section.

For streaming exports, the export history will also display if the streaming export job is currently running or stopped.

Transforming exported data

In general, exports do not support any data transformations executed as part of the export job. This means that the dataset or stream you select to export should already be in your desired format, including filters, renamed or repartitioned files, and any other transformations of the data.

Pipeline Builder and Code Repositories are Foundry's tools for building data transformation pipelines; both applications should provide the complete tooling you need to prepare your data for export, including job scalability, monitoring, version-control, and the flexibility to write arbitrary logic as necessary.

Exports vs. export tasks

Table exports are intended to fully replace the now sunsetted export tasks that will eventually be deprecated according to the published product lifecycle. While much of the functionality offered by export tasks is available in the new export options, there are some differences in the features and configurations.

Migrating from export tasks to table exports

Migrations from export tasks to new export options must be performed manually. Configure your export using the options documented below; once the new export process is working as expected, manually delete the export task that was previously used.

If a feature available in export tasks has no equivalent option in new exports, the recommended migration is to switch to using external transforms. External transforms provide a flexible alternative for executing custom logic that interacts with an external system, and are intended to be used when the UI configuration options for source capabilities do not cover the required functionality.

Feature comparison between exports and export tasks
